力马流化床制粒包衣机FL-100

流化床制粒包衣机

流化床制粒包衣机，属于食品及药品加工设备技术领域。包括顶筒；顶筒内设有左右两个相同的腔室，两个腔室内设有各自的捕集装置，顶筒外在两个腔室的对应位置上设有两个抖动气缸；捕集装置包括捕集袋上固定板、若干个捕集袋、捕集袋下固定板，若干个捕集袋连接在捕集袋上固定板与捕集袋下固定板之间，捕集袋上固定板与万向摇摆部件的下端连接，抖动气缸的伸缩杆与万向摇摆部件的上端连接。通过万向摇摆部件对捕集袋上固定板和抖动气缸进行连接，由于万向摇摆部件的底座和轮体之间可以多方向转动，因此，避免了流化床制粒包衣机运行过程中捕集装置左右晃动对捕集装置与抖动气缸伸缩杆连接部位断裂，延长了其使用寿命。

摘要（英）：The utility model relates to a fluidized bed granulation capsule machine belongs to food and medicine processing equipment technical field. Including a top section of thick bamboo, two the same cavities about being equipped with in the section of thick bamboo of top are equipped with respective entrapment device in two cavities, be equipped with two on the corresponding position of two external cavities in the top section of thick bamboo and tremble actuating cylinder, the entrapment device includes collecting bag an upper fixed plate, a plurality of collecting bag, collecting bag bottom plate, and a plurality of collecting bag connects between collecting bag an upper fixed plate and collecting bag bottom plate, and collecting bag an upper fixed plate is connected with the universal lowerextreme that sways the part, trembles an upper fixed plate 0's telescopic link and is connected with universal upper end of swaing the part. Through universal wave parts to collecting bag an upper fixed plate with tremble actuating cylinder and connect owing to can multi -directionly rotate between universal base that waves parts and the wheel body, consequently, avoided rocking about fluidized bed granulation capsule machine operation in -process entrapment device to the entrapment device with tremble the actuating cylinder telescopic link and be connected the position and split, lengthened its life.
